Quick Details

  • Standard or Nonstandard: Standard
  • Structure: Gate
  • Pressure: High Pressure
  • Power: Manual
  • Material: Forged
  • Temperature of Media: High Temperature
  • Media: Gas
  • Port Size: 1/2" - 4"
  • Place of Origin: Zhejiang, China (Mainland)
  • Model Number: API6agate
  • Brand Name: fly
  • Application: General

Packaging & Delivery

Packaging Details Plywooden case
Delivery Time 10 to 30 days
Product Description

Flanged Forged Steel Gate Valve

Reliable quality,Best price,Top service,Timely delivery

Product details

Product Keywords Flanged Forged Steel Gate Valve,Flanged End Connection Forged Steel Gate Valve,Flange End Connection Forged Gate Valve


Major structures of forged steel gate valve:
1. BODY. The valve body is forged steel and designed to the basic dimensional requirements of the applicable specifications such as API 602 and ASME B16.34. The body is available in both the full or standard port design.
2. BONNET. The bonnet is forged steel, has an integral backseat and incorporates the stuffing box, which has dimensions per the applicable specifications such as API 602.
3. BODY-BONNET JOINT. Two different bonnet joint designs are available. These are either the bolted bonnet or the threaded and seal welded type.
4. GASKET. The bolted bonnet joint design valve uses a contained, controlled compression, spiral wound type gasket.
5. BONNET BOLTING. The bonnet bolting is manufactured of alloy steel in accordance with the requirements of the applicable specifications such as API 602 and ASME B16.34.
6. SEAT RINGS. The seat rings are steel and makeup part of the valve trim. They are pressed into the valve body and wedged into place, forming a seal with the body. The seating surfaces are ground and lapped.
7. WEDGE. The wedge, which is solid design, is forged or investment cast steel and is part of the valve trim. The seating surfaces are ground and lapped
8. STEM. The stem is forged steel and part of the valve trim. It contains an integral back seat shoulder, which mates with the integral backseat of the bonnet. The stem is designed to the basic dimensional requirements of the applicable specifications such as API 602.
9. GLAND AND FLANGE. The gland, gland flange assembly utilizes a separate, two piece design. This self aligning design allows the flange to be unevenly tightened while the gland maintains its parallel alignment with the stem and stuffing box.
10. GLAND BOLTS AND NUTS. The steel/stainless steel gland bolt and nut assembly is a stud, eyebolt arrangement. This design allows complete removal from the valve when service is required. The use of industry standard thread full length studs and nuts also allows easy replacement should these items be lost or in need of replacement.
11. YOKE SLEEVE. The yoke sleeve is of forged stainless steel material having a high melting point and is resistant to wear and corrosion.
12. HANDWHEEL. The handwheel is forged carbon steel of an open spoke design. This robust construction along with appropriate sizing allows for ease of operation.

Quality assurance:

1. Vinner is equiped with world advanced computer driving production lines
2. Whole set of pure water processor line featured with RO anti-saturation and advanced testing devices
3. Manufactured in Class 100,000 Cleanroom

Packaging & Shipping


Standard export carton packing.


3-20 days after confirming order,detail delivery date should be decided according to
production season and order quantity.

Company Information

About us

Cixi Fly Pipe Equipment Co., Ltd.

Cixi Fly Pipe Equipment Co., Ltd. is located in Cixi City, Zhejiang Province. With the completion of the Hangzhou Bay Bridge, it connects Ningbo, Hangzhou and Shanghai. The company is integrates researching, manufacturing, designing, sales and after services as a specialized unit. It always puts the quality at the first place. Our company always persists in the objective of ” honesty and truthfulness, pursuit of high quality, take people at the foremost. we also seek efficiency through effective management and unremitting efforts.

Our key products are :

Valves : Ball valve, Gate valve, Check Valve, Butterfly Valve, Safety valve, Globe Valve; Fittings :butt weld fittings, socket weld fittings,Malleable fittings;

Flanges : Weld neck flange, Slip on flange, Blind flange, Plate Flange;

Sealing; Spiral wound gasket, Rug joint gasket, Gland packing, Rubber gasket;

Composite Meta:Copper/ Steel Clad Plate,Titanium / Steel Clad Plate,Copper/ Aluminum Clad Metal,Stainless Steel/ Steel Clad Metal,Aluminum/ Steel Clad Metal

Others : Seamless pipes, Special pipe, Connecter, Expansion joints etc.

The products are widely applied in the following industries: chemical, petrochemical, oil refinery, energy, offshore drilling, marine, pulp and paper, pharmaceutical, biotech, food and beverage and others.

In the global market with increasing intensive competition, we adhere to the quality first, customer foremost, keeping refining and pioneering from time to time, friendliness, diligence, progress to build up the brand and try to make a leading position in the industry. Welcome new and old customers to cooperate hand in hand, creating brilliance together.

Our Advantages

 High Quality---- Quality Raw Material, Advanced Facilities, Fine Procedures.

 High Productivity

 Fast Delivery

 Leading Level R & D Department

 Experienced Marketing Manager

 Professional Design Department

 Accept OEM & ODM

 Excellent After-sales Service
